Motorola PMAD4133 PMAD4133A UHF 360-400MHz GPS Stubby Antenna
The Motorola PMAD4133 / PMAD4133A is a compact 360–400 MHz GPS stubby antenna designed for compatible Motorola MOTOTRBO portable radios operating in the 350/400 MHz range. Measuring approximately 90 mm, it provides a short antenna profile while supporting GPS functionality on compatible GPS-equipped radios.
- Part Number: PMAD4133 / PMAD4133A
- Frequency Range: 360–400 MHz
- Band: UHF by standard international frequency classification
- Motorola Catalog Classification: Also listed as VHF / 350 MHz band in some Motorola regional documents
- Antenna Type: GPS Stubby Antenna
- Length: Approx. 90 mm / 9 cm / 3.5 in
- Integrated GPS: Yes
- Compatible Radios: DEP550/550e, DEP570/570e, DP2400e, XiR P6600i, XiR P6620i, XiR P6626i, MOTOTRBO R7 and other compatible 350–400 MHz Motorola radios
- Options: Original Motorola or cost-effective compatible antenna
- MOQ: 10 pcs; 1 pc sample available
Motorola PMAD4133 360–400 MHz GPS Stubby Antenna
The Motorola PMAD4133 / PMAD4133A is a compact GPS stubby antenna designed for compatible Motorola MOTOTRBO portable two-way radios operating within the 360–400 MHz frequency range.
Measuring approximately 90 mm / 9 cm, PMAD4133 provides a short and convenient antenna profile for professional portable radios. The antenna incorporates GPS capability for supported GPS-equipped radio configurations.
PMAD4133 is suitable for replacing damaged or missing antennas and for radio dealers, repair companies, system integrators and fleet operators maintaining Motorola 350–400 MHz radio fleets. We can supply both original Motorola antennas and lower-cost compatible replacement antennas.
Specifications
| Brand | Motorola Solutions |
| Part Number | PMAD4133 / PMAD4133A |
| Product Type | Portable Two-Way Radio Antenna |
| Frequency Range | 360–400 MHz |
| Frequency Classification | UHF by standard international frequency-band definition |
| Motorola Regional Nomenclature | May also be identified as VHF / 350 MHz band in Motorola accessory documentation |
| Antenna Type | GPS Stubby Antenna |
| Length | Approx. 90 mm / 9 cm / 3.5 in |
| Integrated GPS | Yes |
| Available Options | Original Motorola / Compatible Replacement |
Frequency Classification Note: Motorola documentation is not fully consistent in its band naming for PMAD4133. Some Motorola Professional Series catalogs classify the 360–400 MHz antenna as VHF or the 350 MHz band, while Motorola’s current online store describes PMAD4133A as a UHF portable radio antenna. Since 360–400 MHz lies above 300 MHz, it falls within UHF under the standard international frequency-band definition.
Compatible Motorola Radios
PMAD4133 is primarily used with regional Motorola MOTOTRBO portable radios configured for operation in the 350–400 MHz range. Compatibility should always be confirmed by the exact radio frequency configuration rather than the radio model name alone.
Europe / International: DP2400e in applicable 350–400 MHz configurations. Availability of this frequency version varies by market.
Asia Pacific: XiR P6600i, XiR P6620i and XiR P6626i in applicable 350–400 MHz configurations. Motorola Japan also documents PMAD4133 as a GPS stubby antenna for regional 350 MHz MOTOTRBO platforms, and Motorola currently lists it as an antenna option for applicable MOTOTRBO R7 configurations.
Latin America: DEP550, DEP550e, DEP570 and DEP570e in applicable 350–400 MHz configurations.
North America: 350–400 MHz versions are not commonly represented by the standard North American XPR portable radio lineup. Please provide the exact radio model and frequency before ordering rather than assuming compatibility with an XPR model.
For purchasing confirmation, please provide the radio model, operating frequency and existing antenna part number. This is particularly important for PMAD4133 because Motorola uses different model names and frequency classifications in different regional markets.
Ordering Information
| Sample | 1 pc sample available |
| MOQ | Usually 10 pcs for handheld radio antennas |
| Product Options | Original Motorola and cost-effective compatible antennas |
| Payment | T/T, Credit Card, WeChat Pay, Alipay |
| Trade Terms | EXW, FOB, FCA, DAP, DDP |
| Typical Delivery | Approximately 4–7 business days to most worldwide destinations |
Frequently Asked Questions
Is PMAD4133 a VHF or UHF antenna?
PMAD4133 operates from 360–400 MHz. By the standard international frequency-band definition, this range is UHF because UHF begins above 300 MHz. However, some Motorola Professional Series catalogs historically classify PMAD4133 as a VHF or 350 MHz-band antenna. Motorola’s current online store describes PMAD4133A as a UHF portable radio antenna.
Does PMAD4133 support GPS?
Yes. Motorola identifies PMAD4133A as an antenna with integrated GPS. GPS functionality is used when the antenna is installed on a compatible GPS-equipped radio.
How long is the PMAD4133 antenna?
Motorola regional accessory documentation specifies approximately 90 mm / 9 cm, making PMAD4133 a compact stubby antenna.
Is PMAD4133A the same as PMAD4133?
PMAD4133A is the commonly documented revision suffix within the PMAD4133 antenna family. Please provide the complete part number from your existing antenna or purchasing record when requesting a quotation.
Does PMAD4133 fit Motorola R7?
Yes, for applicable regional frequency configurations. Motorola’s current store lists MOTOTRBO R7 among compatible devices for PMAD4133A. Because R7 is available in different regional frequency versions, please confirm that your radio operates in the applicable 360–400 MHz range.
Does PMAD4133 fit DEP550 or DEP570?
Yes, for the applicable 350–400 MHz versions. Motorola documentation lists DEP550/DEP550e and DEP570/DEP570e configurations within the radio platform using PMAD4133A.
Can I buy an original Motorola or compatible PMAD4133 antenna?
Yes. We can supply both original Motorola PMAD4133 antennas and lower-cost compatible replacement antennas. Please specify your preferred option when requesting a quotation.
Can I order one PMAD4133 antenna as a sample?
Yes. A 1 pc sample can be requested for compatibility or product quality evaluation. The normal MOQ for handheld radio antenna orders is 10 pcs.
How long does international delivery normally take?
For products available from stock, delivery to most worldwide destinations normally takes approximately 4–7 business days. Actual transit time may vary depending on destination, courier service and customs clearance.
Can you confirm compatibility before shipment?
Yes. Please provide the Motorola radio model, operating frequency, existing antenna part number and required quantity. We can verify the appropriate antenna configuration before shipment.
What happens if there is a product quality problem?
If a confirmed product quality problem occurs, we can arrange a replacement shipment or refund according to the specific order situation. Please provide the order details and relevant information so the issue can be handled promptly.
Can I order PMAD4133 together with other Motorola accessories?
Yes. You can combine antennas with batteries, chargers, microphones, belt clips, earpieces and other Motorola accessories in one order for a combined quotation and consolidated shipment.
Do you offer bulk pricing?
Yes. Bulk quotations are available. Please provide the required quantity and destination country so we can prepare pricing based on the product option, order volume and shipping method.
What payment methods do you accept?
We accept T/T bank transfer, credit card, WeChat Pay and Alipay. Available payment arrangements can be confirmed according to the order amount and destination.
Will tracking information be provided after shipment?
Yes. Tracking information will be provided after shipment so buyers can follow the delivery status of their orders.
Request a Quote for Motorola PMAD4133 Antennas
Send us the PMAD4133 / PMAD4133A part number, Motorola radio model, operating frequency, required quantity and destination country. We can confirm compatibility, stock availability, original or compatible antenna options, shipping method and estimated delivery before you place the order.
